Asymmetric Polycarbonate Canopies

Canopies & Walkways

Asymmetric Polycarbonate Canopies

Asymmetric polycarbonate canopy
TRITON A-Maxx 4.5m x 60m – 16mm Opal Multiwall Polycarbonate Roof – PPC Steelwork / Rainwater System RAL7031 Blue Grey
Asymmetric polycarbonate canopy
Asymmetric polycarbonate canopy at North Birmingham Academy
Asymmetric polycarbonate canopy at The Compton School
Asymmetric polycarbonate canopy - TRITON A-Maxx
Asymmetric polycarbonate canopy at The Compton School - TRITON A-Maxx
Asymmetric polycarbonate canopy at North Birmingham Academy - TRITON A-Maxx
Asymmetric polycarbonate canopy at Saffron Walden County High School

TRITON Maxx-A

For canopies situated alongside buildings, the TRITON Maxx-A with its asymmetric curved roof profile blends seamlessly with the existing architecture. With the potential to powder coat the steelwork to any RAL colour, the canopy can be matched to the adjoining buildings to facilitate fully integrated design. Rainwater flows into guttering to the front edge of the canopy for ease of maintenance.

TRITON canopies are based around a modular design theme, providing a consistent aesthetic and efficient cost structure with the flexibility for specific site requirements and constraints. All of our TRITON canopies are designed and manufactured in accordance with BS EN 1090 EXC 2 accreditation, offering outstanding durability from an all-steel frame with polyester powder coat finish, multiwall polycarbonate roof panels, aluminium glazing system and galvanised steel rainwater goods.

The standard roof specification is the advanced multiwall polycarbonate providing a bright atmosphere without glare, with our proven aluminium glazing system ensuring a reliable and easy to maintain roof cover for the long term. The 25-year structure and 15-year roof covering warranties provide long term peace of mind, with aftercare packages available for periodic inspection and cleaning.

TRITON delivers cost-effective covered space and walkways for use in all weathers, that can be further enhanced with glass or polycarbonate vertical cladding for more exposed locations. See Enclosed Canopies for more information.

REQUEST A QUOTE

Alternatively, try our online tool to get an estimated price for your preferred canopy.

Go to online estimator

TRITON Maxx-A Design Features

  • Glazing & Rainwater Systems

    Streetseal™ aluminium roof glazing system and galvanised powder coated steel rainwater systems for long term reliability.

  • Roof Cladding Options

    Select from multiwall polycarbonate or clearview solid polycarbonate panels.

  • Design Form Flexibility

    The roof radius and column positions can be adjusted to suit adjacent building design.

  • Weather Protection

    Enclosure options include solid or multiwall polycarbonate, planar glass and aluminium glazed curtain walling.

  • Light Transmission

    This must be considered for the use type and the roof cladding can be specified to suit the application.

  • Confidence in Accreditation

    Streetspace design, manufacturing and construction processes are accredited to ISO9001, ISO14001 and BS EN 1090 CE EXC 2.

TRITON Maxx-A Specification & Options

  • Product Specification

    TRITON canopies are available with a number of different forms and support options. Projects are surveyed and modelled prior to detailed design commencement, incorporating existing levels, service cover locations and adjacent door and window positions.

    Canopy Form

    With each structure being individually designed, the radius of the TRITON Maxx-A can be adjusted as required to fit with adjacent buildings.

    Canopy Support

    As well as the standard freestanding design, TRITON canopies are available as either cantilevered structures or wall mounted, providing the wall meets the appropriate structural requirements.

    Canopy Width

    TRITON Maxx canopies can be constructed in widths from 1m to 15m as clearspan structures. Wider spans can be achieved using intermediate columns.

    Canopy Length

    Standard post centres are between 3.5m and 5.5m with variations within the structural design achievable to avoid doorways, access routes or underground services.

  • Roof Type

    While multiwall polycarbonate is the most popular choice of roof cladding for TRITON canopies, other roof types such as glass or steel can be accommodated as bespoke design.

    Multiwall Polycarbonate

    Our most popular roof cladding in the TRITON range, offering a good balance of light transmission and minimal glare. Available in colours if required.

    Clear Solid Polycarbonate

    A cost effective and lighter weight alternative to glass that is significantly more resistant to impact damage.

    Profiled Steel Sheet

    Profiled steel roof cladding is available in a range of standard top coat colours with white underside.

  • Frame Finishes

    Highly durable polyester powder coatings are applied as the standard finish on steel frame TRITON canopies with colours selected from a basic range or from the RAL colour selector. Steelwork is cold grit-blasted to SA2.5, with a zinc coating and anti-corrosive primer, followed by the high gloss polyester colour powder coat finish. Alternatively, hot-dip galvanised coatings can be specified for the harshest environments where a decorative finish is not required. The colours and finishes depicted on this website are representations and should not be taken as accurate.

    • Hot – Dip Galvanised

    • Colour Polyester Powdercoat

  • Canopy Options

    Adding options to your TRITON canopy allows even greater flexibility for extending the use of the covered space.

    Lighting

    Various lighting solutions are available to extend safe use of your covered space or walkway outside of daylight hours.

    IR Heaters

    External grade radiant electric heaters can be fitted to TRITON canopies to provide warmth to users in colder weather.

    Timber Post Cappings

    Adding timber post cappings can help soften the appearance of a steel frame structure.

    Post Protector Pads

    Foam protector pads with heavy duty PVC covers can be fitted to canopy posts for structures situated in play areas.

    Rainwater Systems – Guttering

    TRITON canopies are designed with integral steel guttering, colour powder coated to match the canopy steel frame for long term durability and ease of maintenance.

    Rainwater Systems – Downpipes

    Aluminium downpipes custom manufactured for each canopy with integral connections for maximum durability. Colour powder coated finishes match the guttering and steel frame.

Case Studies for Asymmetric Polycarbonate Canopies
